InGaAs SWIR Short Wave Infrared Technology
Custom Foundry Services
GHOPTO offers professional III-V device fabrication services through its Taiyuan Shanxi China laboratories. These facilities include 1300 square meters of clean rooms (class 100 to class 100,000) for wafer fabrication, chip packaging and device testing. GHOPTO’s engineering can take your optoelectronics fabrication needs from process design, through development stages, and all the way to commercial production in-house.
  • Standard InGaAs Imagers
    Products lines of lattice matched Short-Wave-InfraRed (SWIR) Indium-Gallium-Arsenide (InGaAs) technology. This portfolio includes SWIR and VISIBLE-SWIR linear arrays, focal plane arrays, and cameras.
    More
  • Custom IR Imagers
    Custom ROIC and epitaxy integration, new imaging technologies such as APD, and T2SL FPAs.
    More
  • Foundry Services
    1300 square meters of clean rooms (class 100 to class 100,000) dedicated to wafer fabrication, chip packaging and device testing.
    More
SWIR APPLICATIONS
The short-wave infrared band provides vivid contrast in a variety of processes, ranging from machine vision applications such as pharmaceuticals and packaged goods, to semiconductor inspection and photovoltaics.
About
WHY CHOOSE GHOPTO

GHOPTO is well known as the very first commercial InGaAs (indium gallium arsenide) imaging manufacturer in China. We specialize in creating cost-effective SWIR short wave infrared imaging solutions that meet our clients' specifications, timelines, and budgets in SWIR fields. At GHOPTO, domestic and international clients receive full access to unrestricted performance and full supply-chain control: from the unprocessed starting material to production such as IR imagers/cameras, lasers, waveguides, and systems. With our world-class design and fabrication facility, GHOPTO is ready to take your next project from design to prototype to volume production.
Capacity Milestones Quality Management
